MG996R Digital Servo Motor with Metal Gearbox

High-Performance and Durability for Demanding Applications

The MG996R Digital Servo Motor with Metal Gearbox, available at Robogearbd.com, is engineered for precision and robustness in demanding projects. Featuring a metal gearbox, this servo motor provides exceptional strength and durability, making it ideal for robotics, high-torque applications, and heavy-duty automation tasks.

Why Choose MG996R Digital Servo Motor?

High Torque Output: Delivers impressive torque of up to 11 kg-cm at 6V, suitable for powering large mechanisms or handling heavy loads.
Digital Control: Offers precise and reliable control with digital electronics, ensuring accurate positioning and response.
Metal Gearbox: Equipped with a metal gearbox for enhanced durability and longevity, reducing wear and tear in high-load applications.
Wide Rotation Range: Capable of rotating 180 degrees, offering versatile positioning options for various applications.
Compatibility: Works seamlessly with most microcontrollers and development boards, including Arduino, for easy integration.

Product Specifications

Specification	Details
Operating Voltage	4.8V to 6.0V
No-Load Speed	0.19 sec/60 degrees (at 6V)
Torque	11 kg-cm (at 6V)
Rotation Angle	0 to 180 degrees
Control Signal	PWM (Pulse Width Modulation)
Gearbox	Metal
Dimensions	40.7 x 19.7 x 42.9 mm
Weight	Approximately 55 grams

How to Get Started?

Power the Servo: Connect the VCC pin to a 5V to 6V power source and the GND pin to ground. Ensure your power supply can handle the servo's current requirements, especially under load.
Connect to a Microcontroller: Attach the Signal pin to a PWM-capable output pin on your microcontroller to control the servo's position.
Write Your Code: Use your microcontroller's PWM functions to send control signals to the MG996R. Typically, a pulse width between 1 ms and 2 ms, repeated every 20 ms, controls the servo's angle.
Test the Servo: Upload your code and test the servo's movement. Adjust the pulse width to achieve the desired angle and ensure smooth and accurate operation.
Integrate and Calibrate: Incorporate the MG996R into your project and fine-tune its performance as needed. The robust metal gearbox ensures reliable operation even in demanding applications.

Power your projects with strength and precision using the MG996R Digital Servo Motor with Metal Gearbox. Visit Robogearbd.com to purchase and enhance your designs with high-performance servo motors today!
